Inedge Vault DC3440
3.44MWh 1C Liquid-Cooled Container BESS
Key Features
Fast Power Response
1C architecture supports rapid dispatch and primary frequency response.
Flexibility & High Efficiency
Side-by-side layout and plug-and-play deployment support centralized or string PCS, primary frequency response, and AGC regulation.
Cost & Energy Saving
Smart liquid cooling keeps cell temperature difference below 2°C. Optimized auxiliary power and high-density integration extend lifespan and reduce overall project investment.
AI-powered Intelligence
Cloud-connected APP and mini-program work with smart BMS and SOC/SOH analytics for full-lifecycle tracking and early risk warning.
Layered Safety
Multi-sensor detection, explosion-proof ventilation, and fluoroketone/water fire pipeline provide system protection.
Outdoor Reliability
IP55 enclosure and -30 to 50°C operating range support demanding project environments.
Technical specifications
1C liquid-cooled container BESS for high-response utility and renewable applications.
Product highlights
- Fast Power Response: 1C architecture supports rapid dispatch and primary frequency response.
- Flexibility & High Efficiency: Side-by-side layout and plug-and-play deployment support centralized or string PCS, primary frequency response, and AGC regulation.
- Cost & Energy Saving: Smart liquid cooling keeps cell temperature difference below 2°C. Optimized auxiliary power and high-density integration extend lifespan and reduce overall project investment.
- AI-powered Intelligence: Cloud-connected APP and mini-program work with smart BMS and SOC/SOH analytics for full-lifecycle tracking and early risk warning.
- Layered Safety: Multi-sensor detection, explosion-proof ventilation, and fluoroketone/water fire pipeline provide system protection.
- Outdoor Reliability: IP55 enclosure and -30 to 50°C operating range support demanding project environments.
| Rated energy | 3.440MWh |
|---|---|
| Rated C-rate | 1C |
| Battery type | LFP, 280Ah, 3.2Vdc |
| Battery configuration | 10 * (1P48S*8) |
| Rated voltage | 1228.8Vdc |
| Voltage range | 1075.2-1382.4Vdc |
| Auxiliary power supply | 400Vac +/-5%, 50Hz |
| Dimensions (W*D*H) | 6058*2438*2896mm |
| Weight | 35t |
| Operating temperature | -30 to 50°C (>45°C derating) |
| Protection | IP55 outdoor |
| Corrosion protection | C4 (C5 optional) |
| Cooling | Intelligent liquid cooling |
| Fire detection | Pack 2-in-1 detector, smoke, temperature, and combustible-gas detection |
| Explosion protection | Explosion-proof ventilation |
| Fire suppression | Module/system fluoroketone plus water-based fire pipeline |
| Alarm | Audible-visual alarm |
| Communication | LAN, CAN, RS485, I/O |
| Compliance | GB/T 36276, GB/T 34120, GB/T 34131 |
